Fail. The instrument was unable to complete the probe compensation procedure; the probe may be faulty. Have the probe

checked by Tektronix service personnel.

NOTE. The instrument must pass a Signal path compensation on page 513 procedure before it will perform a probe

compensation procedure.

What do you want to do next?

Learn more about the Probe Compensation controls.

Go to a step-by-step procedure to compensate active probes.

Go to a step-by-step procedure to compensate passive probes.

Learn more about the Vertical controls.

Vertical setups

512 DPO70000SX, MSO/DPO70000DX, MSO/DPO70000C, DPO7000C, and MSO/DPO5000B Series
