To use. Use the Histog tab to select automatic histogram measurements.

1. Select a source with the Channels Selector.

2. Click a Measurements button to add a Histogram measurement to the Measure list:

Histogram measurements

WfmCt Median Pk-Pk U+ /-1S

Hits in Box Max Mean U+ /-2S

Peak Hits Min St Dev U+ /-2S

3. Click Display On in the upper-right corner of the Measurement Setup Control Window to turn the measurement display on

and off.

Oscilloscope reference

DPO70000SX, MSO/DPO70000DX, MSO/DPO70000C, DPO7000C, and MSO/DPO5000B Series 795
