Features not available. Features discussed in this manual that are not available or modified on some instruments or
configurations are noted in the tables.
Table 2: Stand-Alone instrument
Feature DPO77002SX DPO75902SX DPO75002SX DPO73304SX DPO72304SX
State (Clocked Pattern) trigger Not available Not available Not available
XYZ mode Not available Not available Not available
Equivalent time acquisitions on ATI
channels
Not available Not available Not available
HiRes and peak detect on ATI channels Not available Not available Not available
FastAcq on ATI channels Not available Not available Not available
Roll mode on ATI channels Not available Not available Not available
IRE adn MV graticule modes on ATI
channels
Not available Not available Not available
Table 3: Multi-Unit configuration
Feature DPO77002SX DPO75902SX DPO75002SX DPO73304SX DPO72304SX
Line trigger from an extension Not available Not available Not available Not available Not available
Aux trigger from an extension Not available Not available Not available Not available Not available
Runt, Transition, Window, Timeout triggers Mapped
channels
1
Mapped
channels
Mapped
channels
Mapped
channels
Mapped
channels
Period, Frequency Mapped
channels
Mapped
channels
Mapped
channels
Mapped
channels
Mapped
channels
Pattern (Boolean) Not available Not available Not available Not available Not available
Setup/Hold (Clock & Data) Not available Not available Not available Not available Not available
State (Clocked Pattern) Not available Not available Not available Not available Not available
Logic Qualification of Triggers Not available Not available Not available Not available Not available
Low speed serial (I2C, SPI, RS232…) Not available Not available Not available Not available Not available
A-B Trig non-ATI sources Not available Not available Not available Not available Not available
Validation Trigger Type Not available Not available Not available Not available Not available
Frequency Counting Not available Not available Not available Not available Not available
Equivalent time acquisition Not available Not available Not available Not available Not available
FastAcq mode Not available Not available Not available Not available Not available
Roll mode Not available Not available Not available Not available Not available
WfmDB Not available Not available Not available Not available Not available
Limit Test option Not available Not available Not available Not available Not available
1
Mapped channels are channels acquired on the extension instrument that are mapped to (used on) the master instrument.
About Tektronix oscilloscopes
60 DPO70000SX, MSO/DPO70000DX, MSO/DPO70000C, DPO7000C, and MSO/DPO5000B Series
