Acquisition

Using Default Setup

1. To quickly ret

urn to the factory default settings, push

DEFAULT SETUP.

MSO/DPO700

00DX, MSO/DPO70000C, and DPO7 000C Series

MSO5000B and DPO5000B Series

MSO/DPO70000DX, MSO/DPO70000C, DPO7000C, and MSO/DPO5000B Series User Manual 35
