Command Groups
Table 2-34: Waveform Transfer Commands (cont.)
Command
Description
DATa:STOP Sets or returns the ending data point in
waveform transfer
WA VFrm? Returns a branch query containing waveform
data in either binary or ASCII format,
waveform formatting data, and the location of
the waveform data source
WFMInpre? Returns the waveform formatting specification
to be applied to the next incoming CURVE
command data
WFMInpre:BIT_Nr
Sets or returns the number of bits per binary
waveform point for the incoming waveform
WFMInpre:BN_Fmt
Sets or returns the format of binary data for
the incoming waveform
WFMInpre:BYT_Nr
Sets or returns the data width for the
incoming waveform
WFMInpre:BYT_Or Sets or returns the byte order of waveform
points for the incoming waveform
WFMInpre:COMPosition Sets and queries the type of waveform data
to be transferred to the instrument w ith the
CURVe? command.
WFMInpre:FILTERFreq
Sets or returns the byte order of waveform
points for the outgoing waveform
WFMInpre:ENCdg Sets or returns the type of encoding for
incoming waveform data
WFMInpre:NR_Pt
Sets or returns the number of points in the
incoming waveform record
WFMInpre:PT_Fmt
Sets or returns the point format of incoming
waveform data
WFMInpre:PT_Off
This query always returns a 0
WFMInpre:XINcr
Sets or returns the horizontal sampling
interval between incoming waveform points
WFMInpre:XUNit
Sets or returns the horizontal units of the
incoming waveform
WFMInpre:XZEro
Sets or returns the time of the first point i n
the incoming waveform
WFMInpre:YMUlt
Sets or returns the vertical scale factor, per
digitizing level, of the incoming waveform
points
WFMInpre:YOFf Sets or returns the vertical position of the
incoming waveform in digitizing levels
WFMInpre:YUNit
Sets or returns the vertical units of the
incoming waveform
MSO2000B, DPO2000B, MSO2000 and DPO2000 Series Oscilloscopes Programmer Manual 2-55
