Commands Listed in Alphabetical Order
CH<x>? (Query
Only)
Returns the vertical parameters for channel <x>, where x is the channel number.
Group
Vertical
Syntax
CH<x>?
CH<x>:BANdwidth
Sets or returns the selectable low-pass bandwidth limit filter for channel <x>,
where x is the channel number.
Group
Vertical
Syntax
CH<x>:BANdwidth {TWEnty|FULl|<NR3>}
CH<x>:BANdwidth?
Arguments
TWEnty sets the upper bandwidth limit of channel <x> to 20 MHz.
FULl disables any optional bandwidth limiting. The specified channel operates
at its maximum attainable bandwidth.
<NR3> is a double-precision ASCII string. The oscilloscope rounds this value to
an available bandwidth using geometric rounding, and then uses this value to
set the upper bandwidth limit.
NOTE. Other values may be possible depending on the attached probes.
Examples
CH1:BANDWIDTH TWENTY sets the b andwidth of channel 1 to 20 MHz.
CH<x>:COUPling
Sets or returns the input attenuator coupling setting for channel <x>, where x
is the channel number.
Group
Vertical
Syntax
CH<x>:COUPling {AC|DC|GND}
CH<x>:COUPling?
MSO2000B, DPO2000B, MSO2000 and DPO2000 Series Oscilloscopes Programmer Manual 2-99
