Status and Events
Table 3-8: Execution Warning Messages (EXE Bit 4) (cont.)
Code Message
543 Measurement warning, Low resolution
544 Measurement warning, Uncertain edge
545 Measurement warning, Invalid in minmax
546 Measurement warning, Need 3 edges
547
Measurement warning, Clipping positive/negative
548
Measurement warning, Clipping positive
549
Measurement warning, Clipping negative
Table 3
-9: Execution Warning Messages (EXE Bit 4)
Code Message
540 Measur
ement warning
541 Measurement warning, Low signal amplitude
542 Measurement warning, Unstable histogram
543 Measu
rement warning, Low resolution
544 Measurement warning, Uncertain edge
545 Measurement warning, Invalid min max
546 Meas
urement warning, Need 3 edges
547
Mea
surement warning, Clipping positive/negative
548
Mea
surement warning, Clipping positive
549
Me
asurement warning, Clipping negative
Internal Warning
T
he following table shows internal errors that indicate an internal fault in the
oscilloscope.
Table 3-10: Internal Warning Messages
Code Message
630
Internal warning, 50Ω overload
MSO2000B, DPO2000B, MSO2000 and DPO2000 Series Oscilloscopes Programmer Manual 3-17
