Installation Instructions
8 SPG600 & SPG300 Sync Pulse Generators Upgrade Kit
Figure 3: Installing the SD-SDI video outputs board
9. Connect the other end of the flat cable to J1 on the SD-SDI video outputs
board.
10. Use a screw driver with a #2 Phillips tip to reinstall the top cover to the chassis.
11. Remove the protective backing from the label marked “SPG6UP 03” and apply
it to the right side of the instrument, just under the serial number label.
Verifying Instrument Performance
After you have installed the outputs board in this kit, do the performance
verification procedure for the SPG600 as described in the SPG600 & SPG300 Sync
Pulse Generators Service Manual (Tektronix part number 071-1342-XX).
❙❙ End of document ❙❙
