Installation Instructions
SPG600 & SPG300 Sync Pulse Generators Upgrade Kit 7
Installing the 2-Channel SD-SDI Video Outputs Board (SPG6UP 03)
Perform the following procedure to install the 2-channel SD-SDI video outputs
board into your SPG600:
1. Disconnect all external cables and the power cord from the SPG600 rear panel.
2. Use a screwdriver with a #2 Phillips tip to remove the sixteen screws securing
the top cover to the chassis and remove the cover. See Figure 1 on page 5.
3. Use a screwdriver with a #1 Phillips tip to remove the two screws (M2.6 X 6)
securing the blank panel to the rear panel.
4. Use a screwdriver with a #2 Phillips tip to reinstall the blank panel so that the
four BNC connector holes for CH5 to CH 8 are covered with the panel.
If Option 02 is already installed, skip this step.
5. Use a 5.5 mm size nut driver to install the two spacer posts to the chassis.
See Figure 3.
6. Connect the one end of the flat cable provided in the kit at J600 on the A10
Main board. See Figure 3.
7. Use a screwdriver with a #1 Phillips tip to install the two screws (M2.6 X 6)
securing the SD-SDI video outputs board to the rear panel. See Figure 3.
8. Use a screwdriver with a #2 Phillips tip to install the two screws (M3 X 6)
securing the SD-SDI video outputs board to the spacer posts. See Figure 3.
WARNING. Disconnect the power cord from the line voltage source before
installing this option. Failure to do so could cause serious injury or death.
