SPG600 & SPG300 Sync Pulse Generators Upgrade Kit 1
Kit Description
This kit provides parts and instructions to upgrade your sync pulse generator to
Option 01, Option 02, or Option 03.
These instructions apply for the following upgrades:
 SPG3UP 01 (Option 01): adds fine timing adjustment for analog outputs to the
SPG300.
 SPG6UP 01 (Option 01): adds fine timing adjustment for analog outputs to the
SPG600.
 SPG6UP 02 (Option 02): adds 4-channel analog video outputs to the SPG600.
 SPG6UP 03 (Option 03): adds 2-channel SD-SDI video outputs to the
SPG600.
Minimum Tool and Equipment List
Required tools and equipment Description
Screwdriver handle (magnetic) Accepts Phillips-driver bits
#1 Phillips tip Phillips-driver tip for #1 size screw heads
#2 Phillips tip Phillips-driver tip for #2 size screw heads
Nut driver 5.5 mm Standard tool
