Appendix B: Algorithms
TDS 500D, TDS 600B, & TDS 700D User Manual
B–7
Timing measurement. The duration of a burst.
1. Find on the waveform. This is .
2. Find the last (begin the search at and search toward
). This is . This could be a different value from
.
3. Compute = –
Amplitude (voltage) measurement. The mean over one waveform cycle. For
non-cyclical data, you might prefer to use the Mean measurement.
If = then return the (interpolated) value at .
=
ŕ
()dt
( * )
For details of the integration algorithm, see page B–15.
The true Root Mean Square voltage over one cycle.
If = then = .
Otherwise,
=
ŕ
(())
2
dt
( * )
Ǹ
For details of the integration algorithm, see page B–15.
Burst Width
Cycle Mean
Cycle RMS
