Clear and Sanitize Procedures
Table 2: Nonvolatile Memory Devices, (cont.)
Type and
minimum size Function
User
modifiable
1
Data input
method Location To clear To sanitize
Serial Flash
Future expansion No Tested on
power up
Not used
U432 on Main board None None
Serial EEPROM MAC address
No
Set at factory
U221 on Main board None None
1
During normal instrument operation.
Clear Preset
s Procedure
1. Press and hold the PRESET button to display the preset configuration m enu.
Then select Recall Preset > Factory Preset > SEL. This restores the presets
to the factory state.
2. Press and hold the PRESET button. Then select Save Preset > Select Group
A. For all presets that are not empty “<e>”, se lect Save and then press SEL
to overwr
ite that preset with the factory settings.
3. Check each group and overwrite presets that are not empty as described in
the previ
ous step.
4. Navigate to the top level m enu and select Rename Preset. Rename all named
groups a
nd presets with the label “Default”.
Clear Diagnostic Log
Procedure
1. Press the CONFIG button. Then press Utilities > View Diagnostic Log.
Press SEL to display the log.
2. Press > until the box by “Erase Log” is highlighted. Then press SEL to
remove all entries in the diagnostic log.
3. Press > until the box by “Exit” is highlighted. Then press SEL to exit the
log display.
4. Press the CONFIG buttontoexittheconfiguration menu.
Clear IP and SNMP
Address Fields Procedure
1. Press the CONFIG button. Then select Network Settings.
2. Set IP ConfigModeto Manual to display the IP address.
3. Navi
gate toIP Address. Then press > to enter the edit mode. Enter
“000.000.000.000” for the IP address.
4. Repe
at Step 3 for the Subnet Mask, Gateway Address, and SNMP Trap
Address 1 through SNMP Trap Address 4.
5. Pre
ss the CONFIG buttontoexittheconfiguration menu.
WFM6120, WFM7020, and WFM7120 Declassification and Security 3
