Please read these instructions carefully before installing the control unit.
Improper use or a connection error could jeopardise correct operation of the product and endanger
the end user.
1) Terminal board for primary transformer connection
3) 24 V 0.3 A fuse
4) Terminal board for secondary transformer
connection
5) Terminal board for limit switch connection
6) STOP/PROG Pushbutton for Programming and
Stop*.
7) P/P Step/Step button
8) Trimmer for motor power adjustment
9) Jumper Jp1 (for motor power cut-out and soft-start)
10) Connector for OC2 series receiver
11) Function dip-switch
12) TEST jumper
13) Encoder connector
14) Terminal board for low tension connections (24V)
15) ECU reset. Shorting the 2 pins for a moment has the
same effect as switching power off then on again.
16) Indicators LEDs for terminal board inputs. LED on =
input closed
17) Programming LED (L1)
18) Connector for Electric Lock Module
19) Terminal board for 230 V connections
20) Terminal board for mains power supply input
21) 6.3 A fuse for line
22) Terminal board for motor and capacitor connection
* This STOP button must never be considered a safety device, but exclusively a service function to facilitate tests
during installation.
INSTRUCTIONS FOR INSTALLING THE ELECTRONIC CONTROL UNIT T101
PART DESCRIPTION (Fig. 1)
MODELS
Descriptions of the control unit models:
T101: control unit for automation of 1 motor
T101F: control unit for the automation of 1 motor for up-and-over doors
T101FA: control unit with transformer for the automation of 1 motor for up-and-over doors
The control units are equipped with:
- encoder input
- electronic torque adjustment
- motor deceleration
- motor brake
- self-diagnostics of the motor control (Triac Test)
- photocell operation check (Photo Test)
- Soft Start
Important notes:
If motors with internal limit switches are used, for example motors for shutters, the deceleration function must be
switched off (dip 9 OFF), the brake must be switched off (dip 8 OFF) and jumper JP1 fitted (part 9 of fig. 1).
Do not use the deceleration function with hydraulic motors. The gate must always be equipped with mechanical
end stops.
