TECHNICAL DATA
Number of stop relays 2 (potential free*, 16A, 250VAC)
Number of function relays 7 (potential free*, 10A, 250VAC)
Input power 12-24V AC/DC, 48-230V AC
Digital inputs 2
Transistor output 1
Duplex communication Possible
Max. number of registered transmitters 15 (only one transmitter at a time)
IP class 66
Size 176 x 126 x 75 mm./ 6.9 x 5 x 2.9 in.
Weight 800 g./ 1.8 lbs.
Sensitivity Better than -110 dBm
Operating temperature -20- +55°C/ -4-+130°F
Operating frequency
TG-RX-MNL7: 433.075-434.775 MHz
TG-RX-MNR7: 903.0125-926.9875 MHz
TG-RX-MNP7: 2405-2480 MHz
Number of channels/ frequency banks
TG-RX-MNL7: 69 channels
TG-RX-MNR7: 15 banks
TG-RX-MNP7: 16 channels
Channel separation
TG-RX-MNL7: 25 kHz
TG-RX-MNR7: 25 kHz
TG-RX-MNP7: 5 MHz
Antenna
TG-RX-MNL7: 1 external BNC antenna
TG-RX-MNR7: 1 external RPSMA antenna
TG-RX-MNP7: 1 external RPSMA antenna
*potential free means that you have to supply voltage to get voltage out of a relay (e.g. via the included
connection comb)
CURRENT CONSUMPTION
Input power Min.* Max.**
12V AC 0.06A 0.4A
24V AC 0.03A 0.2A
48V AC 0.02A 0.09A
115V AC 0.008A 0.04A
230V AC 0.006A 0.03A
12V DC 0.06A 0.3A
24V DC 0.03A 0.3A
* Minimum current consumption= Receiver powered, no radio session established, nothing else
activated on the receiver
** Maximum current consumption= All relays activated on the receiver
- 11 -
