Right Hand motor wiring Brown 5 – Blue 6 – Black 7
Left Hand motor wiring Black 5 – Blue 6 – Brown 7
Wiring the motor into the control panel
Please ensure you follow each step before moving onto the next page
Please ensure when fixing the control panel to the wall you use the template provided to prevent any damage during installation, failure to do so may
invalidate your warranty.
