Remove the resistor from terminals 16 & 17
Wire your spiral cable into the control panel Brown 16, Green 17, White 18
Wired Safety Edge Set Up
Your spiral cables comes pre-wired into the junction box so all you need to do
is wire the opposite end into the control panel.
If correctly wired and no fault exists the green LED light will be permanently ON inside the junction box
Please ensure you follow each step before moving onto the next page
