Appendix A - Serial Ports
Connector
The standard case uses a DE-9 subminiature 9 pin D connector with female pins
for each serial port.
Pin Signal Direction Notes
1 Data Carrier Detect (DCD) Output
2 Receive Data (RD) Output
3 Transmit Data (TD) Input
4 Data Terminal Ready (DTR)
Alt) Modem Power
Input
Input
[1] [2]
5 Signal Ground (SG) --
6 Data Set Ready (DSR)
Alt) Always in high state
Output
Output
[1] [3]
7 Request to Send (RTS) Input
8 Clear to Send (CTS) Output
9 Not Connected
Alt) Data Set Ready (DSR)
Alt) Modem Power
--
Output
Input
[1] [4]
Pin Signal Direction Notes
1 Data Carrier Detect (DCD) Output
2 Receive Data (RD) Output
3 Transmit Data (TD) Input
4 Data Terminal Ready (DTR) Input
5 Signal Ground (SG) --
6 Data Set Ready (DSR)
Alt) Always in high state
Output
Output
[1] [3]
7 Request to Send (RTS) Input
8 Clear to Send (CTS) Output
9 Not Connected
Alt) Data Set Ready (DSR)
Alt) Modem Power
--
Output
Input
[1] [4]
Connector
The watertight case uses a single 19 pin LEMO HCG.2B.319 connector with
female pins. The recommended mating plug for this connector is a LEMO
FGG.2B.319 series cable mounted connector.
Pin Port Signal Direction Wire Color [6] Notes
1 2 Signal Ground (SG) --
2 2 Data Terminal Ready (DTR) Input
3 2 Transmit Data (TD) Input
4 2 Receive Data (RD) Output
5 2 Data Carrier Detect (DCD) Output
6 1 Signal Ground (SG) --
7 1 Data Terminal Ready (DTR) Input [5]
8 1 Transmit Data (TD) Input
Standard Case
Serial Port 1 Pinout
Serial Port 2 Pinout
Watertight Case
Pinout
