181-122018_THCD-101 Instruction Manual Page 23 of 26
Output current readings r --- ---
Output current readings repeatedly rp --- 0 - 4
P1: 0 = Repeat off
1 = Repeat every 100ms
2 = Repeat every 500ms
3 = Repeat every second
4 = Repeat every minute
Setpoint value spv spv? # P1: Real value to set
Setpoint mode spm spm? 0 - 2
P1: 0 = Auto mode
1 = Open mode
2 = Closed mode
Setpoint source sps sps? 0 - 1
P1: 0 = Internal source
1 = Slave (External) source
Setpoint initial value siv siv? # P1: Real value to set
Setpoint initial mode sim sim? 0 - 2
P1: 0 = Auto mode
1 = Open mode
2 = Closed mode
Retrieve all settings ras --- ---
Comma separated string returned
See Table 3 for actual settings
Ethernet IP address eip eip? IP octets P1: xxx.xxx.xxx.xxx
Ethernet subnet mask esm esm? IP octets P1: xxx.xxx.xxx.xxx
Input channel units string uiu uiu? ccccc P1: Max length 5 chars
Input channel range uir uir? # P1: Real value for range to set
Input channel full scale uif uif? # P1: Real value for full-scale to set
Adaptive filter band flb flb? # P1: Band percentage (0.01-1.00) or
OFF, or ON
Adaptive filter size fls fls? 0 - 6 P1: Buffer size in seconds
Relay switch threshold rlt rlt? 1 – 2,#
P1: Relay number
P2: Real number for switching point
Relay hysteresis rlh rlh? 1 - 2, 0.0 - 10.0
P1: Relay number
P2: Hysteresis percentage value
User input re-zero function irz irz? [0]
P1 (optional): clears current user
input rezero setting
Date of last calibration --- dlc? Returned date format: yymmdd
