181-122018_THCD-101 Instruction Manual Page 7 of 26
Accessories
1.3.1. Power Supplies
Hastings offers power supplies that convert 100, 115 or 230VAC to the 24Vdc voltage required to
operate the THCD-101 and have a circular power plug that will mate with the power jack on the back
of the THCD-101. 24VDC power supply (P/N 12-01-169).
1.3.2. Cables
Hastings offers interface cables to connect the THCD-101 up to Hastings 200/300 series flow
instruments with the standard 15 pin D Connector or the 9 pin D connector used on the 24 Volt versions
as well as the HVG-2020 series of vacuum gauges
±15 Vdc Flow Instruments – 15 pin D connector (std H Pinout)
Stock# Length
65-431 18 inches
65-576 4 feet
65-149 8 feet
65-148 25 feet
65-160 50 feet
65-193 100 feet
65-576-SPECIAL Custom Length cable
±15 Vdc Flow Instruments – 15 pin D connector (U Pinout)
Stock# Length
65-791 8 feet
65-791-99 Custom Length cable
24 Vdc Flow Instruments (includes D300B series) –9 pin D connector
Stock# Length
CB-AF-8-24VM 8 feet
CB-AF-xxx-24VM Custom Length cable
IP-67 Digital Flow Instruments – 12 pin Circular connector
Stock# Length
CB-12PCF-8-AM 8 feet
CB-12PCF-XXX-AM Custom Length cable
HVG-2020 – 9 pin D connector
Stock# Length
CB-AF-8-HVG9M 8 feet
CB-AF-xxx-HVG9M Custom Length cable
Digital AVC – 15 pin High Density D connector
Stock# Length
CB-DAVC-8-AM 8 feet
CB-DAVC-XXX-AM Custom Length cable
More information about the power supplies and cables can be found on the Hastings web site:
http://www.teledyne-hi.com
