Telefunken TKP2198USM - System Diagrams and Sections; Block Diagrams

220VAC
INPUT
Bridge
Rectifier
DB801-
DB804
Power
Transistor
Q801
2SK2996
Transformer
T801
B 33V
+-14V
12V
9V
Q501
Q503
Q505
AMP
CRT
▽ Antenna
IC801
NCP1337
Photo-Coupler
IC803
R
/
G
/
B
P201
Tuner
TU101
IF AMP
Q101
SAW Z2O1
Pin44-46
V.AMP.
IC301
STV8172A
Pin14/15
VDA/B
SCA/SDL
EEPROM
IC001
Pin 56
H.OUT
H.Driver
AMP Q401
Q402
P901
TV/AV/SV
B+
FBT T401
200V
24V
6.3V
pin21
P202
speakerX2
Aout -L/R
KEY &IR001
SENSOR
UOC IC201
Chapter II Block Diagram of NX56 July5,2008
Audio
AMP.
IC601
TDA7266SA
IC701 AN5832SA
IC702 74HC4053
