MODELO: TKP2198USM (Chasis: NX56 VER. P)
Seleccionar Proceso CODIGO DESCRIPCION PROVEEDOR DESCRIPCION ESPAÑOL CANT. UNI. POSICION OBSERVACIONES TOTAL 100 PUENTES
MAIN R 18-FG0339-JSX RMOF 3.3OHM +/-5% 2W R=Y RF MOF 3,3 OHM 2W 5% 1 UN R425A
MAIN R 25-BCB101-M1X CAP.ELE 5MM 100UF 16VV 5X11 85 / CEAP 100 UF 16V +/-20% 6 UN C219;C243;C252;C253;C844;C842
MAIN R 25-BDB471-M1X CAP. ELEC 470 UF 25V +/-20% CEAP 470 UF 25V +/-20% 1 UN C601
MAIN R 25-BEB101-M1X CAP. ELEC 100 UF 35V +/-20% CEAP 100 UF 35V +/-20% 1 UN C307
MAIN R 25-BFB109-M1X CAP. ELEC 1 UF 50V +/-20% CEAP 1 UF 50V +/-20% 11 UN
C216;C251;C250;C249;C248;C247;C246;C245;
C226;C106;C609
MAIN R 25-BFB220-M1X CAP. ELEC 22 UF 50V +/-20% CEAP 22 UF 50V +/-20% 2 UN C317;C319
MAIN R 25-BFB479-M1X CAP. ELEC 4.7 UF 50V +/-20% CEAP 4,7 UF 50V +/-20% 2 UN C205;C318
MAIN R 25-BLB100-M1X CAP. ELEC 10 UF 250V +/-20% CEAP 10 UF 250V +/-20% 1 UN C413
MAIN R 25-GCB102-M1X CAP.ELE 5MM 1000UF 16V 10*20 105 ZT CEAP 1000 UF 16V +/-20% 1 UN C833
MAIN R 26-AIC221-KBX CAP.CER 220P0F 500VV - CCD 220 PF 500V +/-10% B 3 UN C822;C820;C819
MAIN R 26-AIC391-KBX CAP. CER 390 PF 500V +/-10% B CCD 390 PF 500V +/-10% B 1 UN C412
MAIN R 26-AIC470-JZX CAP. CER 47 PF 500V +/-5% SL CCTA 47 PF 50V +/-5% SL 1 UN C418
MAIN R 26-AKC331-KBX CAP.CER 330P0F 1K0V - CCD 330 PF 1000V +/-10% 1 UN C817
MAIN R 26-AKC471-KRX CAP.CER 470P0F 1KVV - CCD 470 PF 1000V +/-10% 1 UN C805
MAIN R 26-AKC472-MEX CAP. CER 4700 pF 1KV +/-20% CCD 4700 PF 1000V +/-20% 2 UN C801;C802
MAIN R 26-EBP561-JCS CAP. CEP 560PF 50V +/-5% CCTA 560 PF 50V +/-5% 1 UN C807
MAIN R 27-MBC104-J0X CAP. M.P.E 0.1 UF 63V +/-5% CPE MYLAR 0,1 UF 63V +/-5% 2 UN C204;C214
MAIN R 27-MBC154-J0X CAP. M.P.E. 0.15UF 63V +/-5% CPE MYLAR 0,15 UF 63V +/-5% 1 UN C208
MAIN R 27-MBC224-J0X CAP. M.P.E 0.22UF 63V +/-5% CPE MYLAR 0,22 UF 63V +/-5% 3 UN C310;C602;C603
MAIN R 27-MCC222-J0X CAP. M.P.E 2200 PF 100V +/-5% CPE MYLAR 2200 PF 100V +/-5% 1 UN C309
MAIN R 27-PBC103-J0X CAP. P.E. 0.01UF 63V +/-5% CPE POLIESTER 0,01 UF 63V +/-5% 1 UN C401
MAIN R 27-PBC222-J0X CAP. P.E 0.0022UF 63V +/-5% CPE MYLAR 0,0022 UF 63V +/-5% 1 UN C406
MAIN R 27-PBC563-J0X CAP. P.E 0.056 UF 63V +/-5% CPE POLIESTER 0,056 UF 63V +/-5% 2 UN C414;C420
MAIN R 34-R100J2-0EX COIL PL - 10 UH +/-5% BOBINA FIJA INDUCTOR 10 UH +/-5% 2 UN L205;L206
MAIN R 35-392170-0IX FERR BEAD BF-I35050R-730 ANILLO DE FERRITE BF-I35050R-730 2 UN L802;L804
MAIN DISIPADOR M 11-CS630F-0CX N-MOSFET CS630F TRANSISTOR MOSFET CANAL-N CS630F 200V 9A 1 UN Q451
MAIN DISIPADOR M 11-DD5024-0CX TR 600V 8_A NPN 35W 1.7MHZ TO-220F 3DD50 TRANSISTOR NPN 3DD5024 8A 1 UN Q402A
MAIN DISIPADOR M 11-S7N60F-0CX MOSFET N 600V 7A 48W TO-220F JCS7N60F TRANSISTOR MOS-FET CANAL N;JCS7N60F, 600V, 7A, 48W, 0.7 ohm 1 UN Q801
MAIN DISIPADOR M 13-DA7266-SAS TCL13-DA7266-SAS= IC TDA7266SA R=N CI AMPLIFICADOR ANALOGICO TDA7266SA 1 UN IC601
MAIN DISIPADOR M 13-LA7814-10P IC LA78141 CI VERTICIAL LA78141 1 UN IC301
MAIN DISIPADOR M 63-B30080-BT4G S/T SCREW B 3 X 8 BT TORNILLO PARA PLASTICO ZINCADO BT 3 X 8 1 UN PARA Q402
MAIN DISIPADOR M 63-B30100-AB4G SCREW-ST 3MM 10MM JIS B 1122 53 0 0 R=Y TORNILLO PARA PLASTICO ZINCADO B 3 X 10 AB 1 UN PARA IC301
MAIN DISIPADOR M 64-P30080-104G M/C SCREW P 3 X 8 TORNILLO METRICO ZINCADO P 3 X 8 4 UN PARA IC601X2; Q451; Q801
MAIN DISIPADOR M 67-H27292-1A0 HEAT SINK DISIPADOR DE ALUMINIO EXTRUIDO 23,5X17X60 1 UN Y451 PARA Q451
MAIN DISIPADOR M 67-H30752-MA0 RAW HEATSINK CRT HA0 00 R=Y DISIPADOR DE ALUMINIO EXTRUIDO 55X25X25 1 UN Y402 PARA Q402
MAIN DISIPADOR M 67-H38013-2A0 RAW HEATSINK -- 02 00 R=Y DISIPADOR DE ALUMINIO EXTRUIDO 61X25X25 1 UN Y801 PARA Q801
MAIN DISIPADOR M 67-H45987-2A0 RAW HEATSINK -- 02 00 R=Y DISIPADOR DE ALUMINIO EXTRUIDO 28X29X50 2 UN Y1;Y2 PARA IC301
MAIN DISIPADOR M 67-H82981-6A0 RAW HEATSINK -- 05 00 R=N DISIPADOR DE ALUMINIO EXTRUIDO 80X37X30 1 UN Y601 PARA IC601
MAIN DISIPADOR M 67-M40068-2E4 TV RAW SUPPORT -- -- 00 00 00 R=N SOPORTE PARA DISIPADOR DE ALUMINIO EXTRUIDO 1 UN Y301 PARA Y1, Y2
MAIN DISIPADOR M 71-270870-0A9 LABEL ETIQUETA 2 UN
MAIN DISIPADOR M 90-0DSTG1-SR1U HEAT SINK DSTG-1 GRASA SILICONADA DSTG-1 0,40 G
MAIN
PREFORMADO
M 10-00RU4C-FPX D-FSR RU4C 1000V 2.5A R=Y DIODO RECUPERACION RAPIDO RU4C 1 UN D808
MAIN
PREFORMADO
M 10-0RU4YX-FPX DIODE GRU4YX (FAST RECOVERY) DIODO RECUPERACION RAPIDO GRU4YX 100V 4A 1 UN D812
MAIN
PREFORMADO
M 10-1N5407-FPX D-FSR 1N5407 800V 3A R=Y DIODO RECTIFICADOR 1N5407 4 UN DB801;DB802;DB803;DB804
MAIN
PREFORMADO
M 10-GBY228-FPX D-FSR GBY228 1500V 2.5A R=Y DIODO RECUPERACION RAPIDO GBY228 1500V 2.5A 1 UN D455
MAIN
PREFORMADO
M 18-CE0332-JNX RES. C.F. 3.3K OHM 1/2W +/-5% RF PC 3,3K OHM 1/2W +/-5% 1 UN R841
TRC A 18-CB0222-JNX RES. C.F. 2.2K OHM 1/6W +/-5% RF PC 2,2K OHM 1/6W +/-5% 3 UN R512;R522;R532
TRC A 18-CB0271-JNX RES. C.F. 270 OHM 1/6W +/-5% RF PC 270 OHM 1/6W +/-5% 3 UN R513;R523;R533
TRC A 18-CB0470-JNX RES. C.F. 47 OHM 1/6W +/-5% RF PC 47 OHM 1/6W +/-5% 3 UN R511;R521;R531
TRC A 18-CD0102-JNX RES. C.F. 1K OHM 1/4W +/-5% RF PC 1K OHM 1/4W +/-5% 1 UN R541
TRC A 18-CD0471-JNX RES. C.F. 470 OHM 1/4W +/-5% RF PC 470 OHM 1/4W +/-5% 6 UN R516;R518;R526;R528;R536;R538
TRC A 18-CE0224-JNX RES. C.F. 220K OHM 1/2W +/-5% RF PC 220K OHM 1/2W +/-5% 1 UN R506
TRC A 18-FE0272-JNX RESISTOR METAL OXIDE FILM 2K7OHM 5% 1/2W RF OM 2,7K OHM 1/2W +/-5% 3 UN R539;R529;R519
TRC A 26-EBP391-JCS CAP. CER 390PF 50V +/-5% CCTA 390PF 50V +/-5% CH 3 UN C511;C521;C531
TRC A 26-EBP561-JCS CAP. CEP 560PF 50V +/-5% CCTA 560 PF 50V +/-5% 1 UN C541
TRC A 34-A470K2-1IX COIL CHOKE 47 UH +/-10% (5MM) BOBINA FIJA INDUCTOR 47 UH +/-10% 1 UN L501
TRC A 41-0J0000-00X WIRE BARE JUMPER ALAMBRE DE COBRE ESTAÑADO 0,0005 UN JP503;JP502;JP501;J505 4 WIREBAREJUMPER 5MM
TRC A 41-0J0000-00X WIRE BARE JUMPER ALAMBRE DE COBRE ESTAÑADO 0,0004 UN D521;D511;D531 3 WIREBAREJUMPER 6.5MM
TRC A 41-0J0000-00X WIRE BARE JUMPER ALAMBRE DE COBRE ESTAÑADO 0,0001 UN J504 1 WIREBAREJUMPER 7.5MM
TRC A 41-0J0000-00X WIRE BARE JUMPER ALAMBRE DE COBRE ESTAÑADO 0,0001 UN J502 1 WIREBAREJUMPER 9MM
TRC A 41-0J0000-00X WIRE BARE JUMPER ALAMBRE DE COBRE ESTAÑADO 0,0001 UN J503 1 WIREBAREJUMPER 10MM
TRC M 26-AMM102-KRX CAP.CER 1N0F 2KVV - CCD 1000 PF 2KV +/-10% R 1 UN C505
TRC M 46-10967W-01XG SMD PIN BASE *1 TJC1-1A CONECTOR PARA IMPRESO DE 1 VIA 1 UN P503
TRC M 46-33079W-06XG PIN BASE *6 TJC3-6A CONECTOR PARA IMPRESO DE 6 VIAS 1 UN P501
TRC M 46-35179W-04XG PIN BASE TJC3-4A CONECTOR PARA IMPRESO DE 4 VIAS 1 UN P502
TRC M
47-CRT022-NX0G CRT SOCKET GZS10-2-DD2 (DQ5)
CONECTOR ZOCALO DE TRC 1 UN S501A
TRC PCB 40-0NX56B-CRE1XG TV PCB CR BD R=Y CIRCUITO IMPRESO FENOLICO SIMPLE FAZ TRC 40-0NX56B-CRE1XG 1 UN
TRC R 11-0BF422-0BX TRANSISTOR BF422 (NPN) 126 TRANSISTOR NPN BF422 3 UN Q512;Q522;Q532
TRC R 11-0BF423-0BX TRANSISTOR BF423 (PNP) 126 TRANSISTOR PNP BF423 3 UN Q513;Q523;Q533
TRC R 11-SC2482-0BX TRANSISTOR 2SC2482 TRANSISTOR NPN 2SC2482; 300V 100mA; 900mW 3 UN Q511;Q521;Q531
TRC R 18-FG0153-JSX RMOF 15KOHM +/-5% 2W R=Y RF OM 15K OHM 2W 5/-5% 3 UN R515A;R525A;R535A
