Page 27 of 27
TVP Manual (full) March 2007 CE rev 03.doc
Diagram 14a
TVP 2000/3500 single coil unit
valve arrangement
Diagram 14b
TVP 2000/3500 dual coil unit valve
arrangement
Valve box
1. Access hand valve
2. Suction (common return valve)
3. Common defrost hand valve
4. Defrost solenoid valve coil 1.
5. Defrost solenoid valve coil 2.
6. Start valve
7. Common cool hand valve
8.
Cool solenoid valve coil 1
9. Cool solenoid valve coil 2.
