TM106601_(7/01) 2-1
USE OR DISCLOSURE OF DATA CONTAINED ON THIS PAGE IS SUBJECT TO THE
RESTRICTION ON THE TITLE PAGE OF THIS DOCUMENT.
COMMAND SYSTEMS DIVISION
2.1 GENERAL
This chapter contains information for the installation of the Telephonics RDR-1600 Weather Radar
System. Included are equipment outline drawings, installation pictorials and electrical interconnect
diagrams of the different system configurations. These drawings should be reviewed by the installing
agency and requirements peculiar to a particular airframe established before installation is begun.
2.2 UNPACKING
Use care when unpacking the Telephonics RDR-1600 Weather Radar System components. Open
shipping cartons and carefully remove all items. Check the components to ensure that all items
ordered have been included. Retain shipping cartons and packing material for future shipping or
storage.
Visually inspect all units for any possible damage that may have occurred during shipment, such as
dents, deep abrasions, chipped paint, cracked glass, etc. If any equipment has been damaged in
transit report the extent of damage to the transportation carrier immediately.
2.3 PRE-INSTALLATION CHECK
Bench test the equipment to ensure that it is operable before installation. Bench test procedures are
given in the RDR-1600 Maintenance Manual. A continuity and insulation test should be made on all
cables and wiring harnesses fabricated by the installing agency.
2.4 INSTALLATION PLANNING
2.4.1 Outline and Interconnect Drawings
Outline drawings of the units in the RDR-1600 radar system and the interconnect diagrams are
located at the end of this chapter. Interconnect diagrams provide for either an analog gyro system or
an AHRS system installation.
For interconnecting information, refer to Figure 2.9-8 for an analog gyro system and Figure 2.9-9 for
an AHRS system installation.
The installer must fabricate cable assemblies. Mating connectors are not supplied with each unit of
the system. See Table 1.3-1.
2.4.2 Location of Equipment
The locations chosen for units of the RDR-1600 Weather Radar System, and the method of
installation will vary with each particular type of aircraft. The units should be installed in a
