Specifications (w/ LPC1 Coupler & GVFD Display)
After factory calibration, preliminary data subject to change without notice.
See other couplers below.
Useful Power Range: 0.05W to ~ 3,000W
Nominal Impedance: 50 ohms
Absolute Power Accuracy: 5% or better, 1W to 3KW… 3% or better typical
Band to band Power Variation: 1% or better from 1.8 to 54 MHz
SWR Range: 1.00 to 9.99
SWR Accuracy: <.15, typically <.05 or below over 99% of power range
Directivity: >30 dB over rated coupler frequency range (40 dB typical)
Insertion Loss <0.05 dB
Impedance: 0-999.9 ohms Z, R and |X|, <5% typical, 10-250 ohms
Phase: 0-180.0 degrees, <5 degrees (<3 degrees typical, 10-170 degrees)
Frequency counter: 1 MHz to >100 MHz, +15 to +23 dBm sensitivity (~0.1% accuracy)
Power handling: LPC1 Coupler - 1,500W CCS, 3,000W ICAS – Others below
Bargraph response: >50 Hz
Bargraph resolution: 90 steps
Direct Inputs: -15 to +33 dBm, 50 ohms, 0.1 to 650 MHz +0/-1.5 dB, 2W max
DC Power: 11-16 VDC @ 270-330 mA (depends on brightness setting).
Operating temp range: 0 to 50 degrees C
Clock: 40 mHz
Program memory: 64kB
Size: Controller: 6.0" x 6.0" x 2.75" (15.24cm x 15.24cm x 6.99cm)
Coupler: 2.25” x 2.40” x 5.00” (5.72cm x 6.1cm x 12.7cm)
Weight: 3 pounds (1.36 kg)
Optional couplers:
LPC2 0.10W to 5,000W CCS, 1.8 to 30 MHz
LPC3 0.05W to 250W CCS, 10 KHz to 54 MHz
LPC4 0.10W to 5,000W ICAS, 1.8 to 54 MHz(3KW on 6 meters)
LPC5 0.20W to 10,000W ICAS, 1.8 to 30 MHz
LPC6 0.20W to 1,000W ICAS, 100KHz to 20 MHz
CAL Table
Log the initial CAL constants for your LP-100A in this table. If you ever make changes, you can log additional constants in the spaces
provided.
