Telestone TS-OR02RDBS-30 - Unit Descriptions

Ver. 0 9
3.2. Unit Descriptions
1. LAN and Dry Contact Interface board
2. PSU (Power Supply Unit)
3. MS Duplexer
4. Battery for Control Unit
5. Modem
6. BS Directional Coupler
7. Downlink Integrated Module
8. Uplink Integrated Module
9. BS Duplexer
10. Keypad and LCD
11. Control Unit board
12. Door Switch


1
2
3
4
5
6
7
8
9
10
11
N
+9V- A DJ
L
TS-SD Y03-27V/4AⅢ
+27V
GND
GND
+27V
+12V-AD J
+12V-AD J
GND
GND
PE
12
