Eclipse 8/ 16/ 32 Series - Engineer Programming Manual
8
Summary for ECLIPSE Series Keyboards:
Keyboard
Display
Areas
Zones
Proxi
Address
Operation
Text menu
AUX PGM
LED 8
LED
1
8





LED 16
LED
2
16





LED 16A
LED
3
16





LED 32
LED
8
32
 (option)




LCD 32
LCD
8
32
 (option)




LCD 32S
LCD
8
32





2.2 Sound Signalization from the Keyboards
All Eclipse Series Keyboards have sound signalization for occurring of different system events. The sound signalization
has 4 volume levels adjustable at address 90 from the Manager programming menus.
Sound Signal
Description
Button
Single short beep indicating the pressing of a key.
Confirmation
Two long sound signals, indicating the system confirmation to executed operation.
Cancel
operation
A single long beep, indicating system incorrectly executed operation.
Entry time
Continuous beep, indicating intrusion into an entrance zone.
Exit time
Short beeps, indicating the system is armed and the user is required to leave the entrance zone.
Ten seconds before the exit time is over beep frequency increases.
Technical
problem
Two short beeps at every 20 sec, indicating a technical trouble. To stop the signalization - press the
TROUBLE button.
Chime
Short beeps with subsequently increasing period, indicating intrusion into a zone with an activated
chime option.
Fire alarm
Three sound signals in sequence repeated every 5 seconds. That kind of signalization shows
activated fire detector in the premises.
2.3. Supported Trouble Events in ECLIPSE Series
The possible system troubles are listed in the table below, together with the respective indication for LED and LCD
keyboards. The sound signalization for a system trouble can be disabled in menu 2. SETTINGS – 03. TRBL SOUNDS
(ADDRESS 0013 or OPERATION 013. By default, the sound signalization for all system troubles is enabled.
Note: The system troubles 7 and 8 are not supported for Eclipse 8/ 16 control panel.
LED
LCD
Description

1. AC Loss
The mains power supply is lost.

2. Battery Trouble
The accumulator battery is discharged or missing.

3. Blown fuse
Blown out fuse.

4. Tel. line TRBL/
Comm. Fail
Telephone line of the digital communicator is lost & communication with central Monitoring
station fails.

5. Tamper
Open tamper in system.

6. Sysbus err
System bus error. It could be short circuit in the line or lost device.

7. Fire line Error
Fire Detector Loss or the fire line is broken.

8. Siren Fault
Problem with connected siren; no siren connected to PGM5.
