Teletek electronics ECLIPSE 8 - Page 85

Eclipse 8/ 16/ 32 Series - Engineer Programming Manual
85
To the 3.User CODES Menus
2. SETTINGS
01. AMBUSH CODE
Disable / Enable
02. KBD BLOCK
Disable / Enable
03. TRBL SOUNDS
 AC LOST
 BATT TROUBLE
 BLOWN FUSE
 PSTN TRBL
 TAMPER
 SYSBUS TRBL
 FIRE LINE TRBL
 SOUNDER TRBL
04. CONFIG. TIMER
10 – 180 sec; [010]
05. AC DELAY
000 – 255 min; [030]
06. SOUNDS TMPR
Disable / Enable
10. RESET MNG
Pass: 0000
11. SYSTEM NAME
12. TIME
[00:00]
13. DATE
[01/01/12]
14. MENU STYLE
ADDRESS
OPERATION
 TEXT
07. ALARM DELAY
Disable / Enable
08. HWR RESET
Disable / Enable
09. PART DEFAULT
1. SETTINGS
2. CODES
3. INPUTS
4. OUTPUTS
5. PARTITIONS
6. SCHEDULES
7. COMMUNICATION
8. DEVICES
Use for menus 09, 10 and 15!
Partial reset:
Choose the menu you want to
reset. Select it with the arrow
buttons. Enter in sequence
1,2,3,4, 5 and 6, and confirm
with ENTER.
NOTE!
Use button:
to ENABLE
NOTE!
Use buttons:
to DISABLE
to ENABLE
or
02. CHIME (Eclipse 8)
