- If the meter has a digital measurement window open (Power or C/N) it will be impossible to
see the scart signal, although this may be in auto mode. Therefore, if you wish to see the
scart signal, make sure that the meter is not carrying out a digital measurement.
- If you wish to see any TV signal onscreen, it is worth remembering that you can remove all the
menus from the screen by using the Clear/Menu button, and the measurement windows by
using the button or by accessing the Viewing Mode menu.
3.3.2.6.- Information about the equipment
When this function is selected, a window will open which will display information about the
equipment, as can be seen below:
Figure 45.- Window displaying equipment information
3.3.2.6.1- Update
Using this option we can load the licence number in order to activate an options packet.
Serial number
Model
Software version
Voltage measured
in the battery
Multimetter FSM 500 Ref. 5903
48
