LE910Cx Hardware Design Guide
1VV0301298 Rev.40 Page 97 of 149 2023-03-16
Not Subject to NDA
Figure 27: LE910C1-APX Mechanical Dimensions (Top view) with frame and cover shield design
Note: LE910Cx-AP/APX/NA/NA/NS/EU/NF/NF/ST/SA has two shield
designs and LE910Cx-SV/SVX/LA/CN/EUX/SAX/WWX has one shield
design.
