Tellus Power TP5-30-480 - Specifications

TELLUS POWER GREEN
DC FAST CHARGER
Specifications
Tellus Power Green
23541 Ridge Route Drive Suite B
Laguna Hills, CA 92653
United States
www.telluspowergreen.com
Product # TP5-30-480
Input 480VAC (3P+N+PE)
Frequency 60Hz
Output Voltage 150 to 1000VDC
Output Current 0 to 100A
Connector(s) CCS1 or CHAdeMO
Efficiency ≥94% at nominal output power
Power Factor > 0.98
Operating Temperature
22°F to 131°F (-30°C to 55°C)
Working || Storage humidity ≤ 95% RH || ≤ 99% RH (Non-condensing)
Altitude < 6600ft (2000m)
Display 7’’ LCD with touch screen
RFID system ISO || IEC 14443A/B
Dimensions (l x d x h) 21’’ x 12’’ x 27’’
Protective Class NEMA 3S, IK 10
Cooling System Air cooled
Weight 176 lbs (80kg)
Charging Protocol
Mode 4, IEC-61851, ISO-15118, DIN SPEC 70121
Mode 4, CHAdeMO 0.9, 1.0
Length of charging cable 16ft (5m)
Interface protocol OCPP 1.6J
Communication Ethernet / 4G Wi-Fi
Electrical Safety: GFCI RCD 20 mA Type A (UL)
Electrical Safety: Surge Protection 20 kA
Electrical Safety General Over Voltage, Under Voltage, Over Current, Missing Ground
Electrical Safety: Output Short Output power disabled when output is short circuited
Electrical Safety Temperature
Temperature Sensors @ Charge Coupler and Power
Electronics
Emergency Stop Emergency Stop Button Disables Output Power
Regulatory Compliance
UL-2202 || EMC: EN 61000-6-1:2007, EN 61000-6-
3:2007/A1:2011/AC:2012
