Mounting Charger Holster to Pedestal
Remove access panel on the left side of the charger. Locate the holes that will secure the holster. Now align holster with
holes and fasten down using the screw sizes provided below (not included).
• Bolt
• Nut
• Washer
Left Side
Right Side
