RJ45 LED MEANING
POWER SOCKET PINOUT
TECHNICAL INFORMATION
* PoE operates properly only when connected power supply outputs 44 V or higher voltage.
** Provided power supply only allows 60 W PoE power budget at PSE, to reach maximum 120 W at PSE >130 W power supply must be used
*** Order code dependent.
Technical specifications
Bundled accessories specifications***
Input voltage range*
Max PoE power budget at PSE**
Max power consumption no PoE devices connected
7 – 58 VDC
<9 W
120 W
Max Ethernet cable length
100 m
Power adapter
Input: 1.8 A @100-240 VAC, Output: 50 VDC, 1.3 A, 4 pin plug
