Teltonika TSW100 - Hardware Installation

1. Connect your main internet router/modem to TSW100 LAN port number 5.
2. Connect end devices (ex. IP camera) to TSW100 1 to 4 port, which you want to power via Ethernet.
3. Connect 4 pin power plug to TSW100 to power up switch.
HARDWARE INSTALLATION
1 32
PoE OUT
4 5
IP camera
TRB140
IP camera
