Tempco TPC-1000 User Manual

Page 8 of 18
1.2 Parameter Description
(*Parameters that are not applicable are not shown)
Register
Address
Parameter
Notation
Parameter Description Range
Default
Value
0
SP1
Set Point 1
(Used for Output 1)
Low: SP1L
High: SP1H
77.0°F
8
INPT
(See Pg. 11)
Input sensor selection
0 J_tC: J type Thermocouple
1 K_tC: K type Thermocouple
2 T_tC: T type Thermocouple
3 E_tC: E type Thermocouple
4 B_tC: B type Thermocouple
5 R_tC: R type Thermocouple
6 S_tC: S type Thermocouple
7 N_tC: N type Thermocouple
8 L_tC: L type Thermocouple
9 U_tC: U type Thermocouple
10 P_tC: P type Thermocouple
11 C_tC: C type Thermocouple
12 D_tC: D type Thermocouple
13 Pt.dN: PT100 Ω DIN curve
14 Pt.JS: PT100 Ω JIS curve
15 4-20: 4-20mA linear current input
16 0-20: 0-20mA linear current input
17 0-5V: 0-5VDC linear voltage input
18 1-5V: 1-5VDC linear voltage input
19 0-10: 0-10VDC linear voltage
input
0, 1 or 13
(Depends on
Model Ordered)
9
UNIT Input unit selection
0 oC:°C unit
1 oF:°F unit
2 Pu:Process unit
1
10
DP Decimal point selection
0 No.dP: No decimal point
1 1-dP: 1 decimal digit
2 2-dP: 2 decimal digit
3 3-dP: 3 decimal digit
0
13
SP1L
Low limit of set point 1
(Span Value)
Low: -19999
High :SP1H
0.0° F
14
SP1H
High limit of set point 1
(Span Value)
Low: SP1L
High: 45536
1000.0°F
15
FILT
Filter damping time constant of
PV Sensor
(See Pg. 14)
0
0
: 0 second time constant
1 0.2: 0.2 second time constant
2 0.5: 0.5 second time constant
3 1: 1 second time constant
4 2: 2 second time constant
5 5: 5 second time constant
6 10: 10 second time constant
7 20: 20 second time constant
8 30: 30 second time constant
9
60
: 60 second time constant
2
