Tempcool TC-120B3 - Unit Specifications and Rating Information

1|Page

UnitSpecificationsandRatingInformation












Specifications TC‐120B3 TC‐120B4
CoolingCapacity(80
o
FDB/67
o
FWB) 131,000 131,000
PowerSupplyVolts/Ph/Hz 208‐230/3/60 460/3/60
ThermostatControl Electronic Electronic
MeteringDevice TXValve TXValve
PowerConsumption,kW 13.7 12.6
CurrentConsumption,Amps 59 27.5
MinimumCircuitAmpacity(MCA)‐‐ Amps 68 32
MaximumOvercurrentProtection(MOP)‐‐ Amps 100 45
ElectricalConnection Wired Wired
EvaporatorCFM 4,000 4,000
EvaporatorDuctConnections,Dia.In. 20 20
CondenserCFM 6,000 6,000
CondenserDuctConnections,Dia.In. 20 20
MaximumESP 1.0 1.0
CondensatePumpHead,ft. 15 15
OperatingLimits,(min.
–
max.)
o
F 60‐110 60‐110
SoundLevel,dB ?? ??
R‐410ACharge,lbs. 21.0 21.0
LxWxH,in. 86x 35x78 86x35x78
Weight,netwt/shippingwt,lbs. 1860/1860 1860/1860
