Tempur-Pedic Sleeptracker STS-40A - Quick Reference Guide

6
Not to scale. For illustration purposes only. Read all instructions before beginning installation.
quick reference guide
Power Cord
Input
Power Cord
Power Supply
Control Box
connection
ports
to head and
foot motors
(massage and
lift). Installed
under the base.
Battery
Backup Box
USB Charging Ports
USB Charger
Splitter
Underbed Lighting
Sleeptracker
®
Sensor
Sleeptracker
®
Sensor
Sleeptracker
®
Processor
USB
Extension
Cable
Sleeptracker
®
Smart Cable
