95
PPPoEv6
Overview
If your ISP provides you with the PPPoE user name and password with IPv6 service, you can choose
PPPoEv6 to access the internet.
Log in to the web UI of the router, and navigate to the IPv6. When the connection type is set to
PPPoEv6, the page is shown as below.
Parameter description
Parameter
Description
PPPoE Username
It specifies the PPPoE user name and password provided by your ISP.
IPv4 and IPv6 services share the same PPPoE account.
PPPoE Password
Obtain IPv6 Prefix
Delegation
When the option is selected, the LAN port of router obtains IPv6 prefix from it upstream
device.
It is recommended to keep the default setting (Selected). If the LAN port cannot obtain
the PD prefix, it is because the upstream device does not support PD prefix delivery.
Contact your ISP to solve this problem.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Tenda AC23 and is the answer not in the manual?

Tenda AC23 Specifications

General IconGeneral
USB portNo
DC-in jackYes
Connectivity technologyWireless
Ethernet LAN (RJ-45) ports3
Product typeTabletop router
Product colorBlack
LED indicatorsLAN, System, WAN, WLAN, WPS
Wi-Fi bandDual-band (2.4 GHz / 5 GHz)
Wi-Fi standards802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standardWi-Fi 5 (802.11ac)
WLAN data transfer rate (max)2033 Mbit/s
WLAN data transfer rate (first band)300 Mbit/s
WLAN data transfer rate (second band)1733 Mbit/s
VPN supportIPsec, L2TP, PPTP
Networking standardsIEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Ethernet LAN data rates10, 100, 1000 Mbit/s
Ethernet LAN interface typeGigabit Ethernet
Transmit power20/23 dBmW
Antennas quantity7
Antenna gain level (max)6 dBi
Output current1.5 A
Output voltage12 V
AC input voltage100 - 240 V
Power source typeAC
AC input frequency50 - 60 Hz
CertificationCE/FCC/RoHS
Processor cores2
Processor frequency1000 MHz
Cables includedLAN (RJ-45)
Storage temperature (T-T)-40 - 70 °C
Operating temperature (T-T)0 - 40 °C
Storage relative humidity (H-H)5 - 90 %
Operating relative humidity (H-H)10 - 90 %
Security algorithmsWPA, WPA-PSK, WPA2, WPA2-PSK
Harmonized System (HS) code85176990
Weight and Dimensions IconWeight and Dimensions
Depth144.3 mm
Width238.9 mm
Height40.3 mm
