Tenda AC23 User Manual

84
Parameter description
Parameter
Description
FTP
Server
Encoding Type
It specifies the encoding type for the text content on the FTP server.
⚫
Unicode (utf-8): It is an encoding type for international use, which is
compatible for most languages in the world. It is recommended when there
are more English texts.
⚫
Simplified Chinese (GBK): It is a simplified Chinese character encoding
standard. It is recommended when there are more simplified Chinese texts.
⚫
Traditional Chinese (Big5): It is a traditional Chinese character encoding
standard, which is widely used in Taiwan and Hong Kong. It is recommended
when there are more traditional Chinese texts.
Allow Internet
Access
It is used to allow or block the access to the FTP server on the USB storage
device from the internet.
Access from
Internet
It specifies the address for internet users to access the FTP server on the USB
storage device and will be automatically generated according to the WAN IP
address of the router when the Allow Internet Access function is enabled.
⚫
Please ensure that the WAN IP address of the router is a public IP address.
Otherwise the access could fail.
⚫
Change the port number in the address if necessary.
LAN Address
It specifies the address for users within the LAN of the same router to access
the FTP server.
Samba
Server
Address for
Windows OS
It specifies the address for users within the LAN of the same router to access
the Samba server, using a computer of Windows OS.
Address for
MAC OS
It specifies the address for users within the LAN of the same router to access
the Samba server, using a computer of MAC OS.
Role
It specifies the role you use when logging in to the FTP or Samba server. Two
roles are available for logging in, whose permissions differ.
⚫
Administrator: Log in to the FTP or Samba server as an administrator, who is
able to read and write files.
⚫
Guest: Log in to the FTP or Samba server as a guest, whose permission can be
set to either Read or Read/Write.
User Name
It specifies the user name and password for logging in to the FTP or Samba
server. The user name of the administrator account cannot be changed.
Password
Permission
It specifies the permission for the respective role. The administrator is pre-set
with the read/write permission and cannot be changed.
⚫
Read/Write: Users with such permission can both view and edit the files on
the FTP or Samba server (To edit means to upload, download, delete or
rename).
⚫
Read: Users with such permission can only view and download the files on the
FTP or Samba server.

Tenda AC23 Specifications

General

USB port	No
DC-in jack	Yes
Connectivity technology	Wireless
Ethernet LAN (RJ-45) ports	3
Product type	Tabletop router
Product color	Black
LED indicators	LAN, System, WAN, WLAN, WPS
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	2033 Mbit/s
WLAN data transfer rate (first band)	300 Mbit/s
WLAN data transfer rate (second band)	1733 Mbit/s
VPN support	IPsec, L2TP, PPTP
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Transmit power	20/23 dBmW
Antennas quantity	7
Antenna gain level (max)	6 dBi
Output current	1.5 A
Output voltage	12 V
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Certification	CE/FCC/RoHS
Processor cores	2
Processor frequency	1000 MHz
Cables included	LAN (RJ-45)
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Security algorithms	WPA, WPA-PSK, WPA2, WPA2-PSK
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	144.3 mm
Width	238.9 mm
Height	40.3 mm
