Tenda AC8 Quick Installation Guide

- 4 -
- WiFi password: Used to connect to the WiFi network.
- Login password: Used to log in to the web UI of the router.
If you cannot access the internet after the configuration, refer to Q2 in FAQ.
To access the internet:
➌ Set WiFi name, WiFi password and login password of the router, and then
click Next.
Done.
WiFi Settings
Tenda_XXXXXX
WiFi password of 8-32 characters
Not Required
Set the WiFi password as the login password of the
admin account.
Not Required
Login password of 5-32 characters
Next
Tips
You’re all set! You can now connect to
Tenda_XXXXXX
or Tenda_XXXXXX_5G
To change settings of other features,click the "More" button below.
More
Tips
- WiFi-enabled device: Connect to the WiFi network with the WiFi name and password you set.
- Wired device: Connect your device to a LAN port (1, 2 or IPTV/3) of the router using an
Ethernet cable.

Tenda AC8 Specifications

General

DSL WAN	No
Ethernet WAN	Yes
Product type	Tabletop router
Product color	Black
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Ethernet LAN (RJ-45) ports	4
Antenna gain level (max)	6 dBi
Output current	1 A
Output voltage	9 V
AC input voltage	200 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (first band)	300 Mbit/s
WLAN data transfer rate (second band)	867 Mbit/s
Firewall security	Forbid WAN PING from internet
Security algorithms	WPA, WPA-PSK, WPA2, WPA2-PSK
Certification	CE, FCC, CCC, SRRC
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Cables included	LAN (RJ-45)
Package type	Box
Number of products included	1 pc(s)
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	127 mm
Width	200 mm
Height	33.6 mm
