8
3
Connect the device
The K4P-4CR kit is taken as an example here.
Router
Internet
Computer
LAN
LAN
PoE
WAN
PoE NVR
OUT
POWERPOWER PoE PORTS LAN AUDIO HDMI
13
24
VGA USB1 USB2
IN
Ethernet cable
HDMI cable or
VGA cable
Monitor
PoE cameraPoE cameraPoE cameraPoE camera
LAN
