Tenda W300D Technical Specifications

WHAT THIS PRODUCT DOES
BENEFITS
TECHNICAL SPECIFICATIONS
Create a 300Mbps WLAN to enjoy and share streaming
HD movies, music, digital photos and big files from
multiple PCs simultaneously
Multiple access modes like PPPoE, PPPoA,MER, IPoA
and Bridge
Simple but powerful web management
Advanced Security Network by WPS, WPA and WPA2
Dual SSIDs creates two separate LANs for privacy
purposes
Up to 300Mbps
Reset, Power
2.4GHz~2.4835GHz
DC 12V,1A
0ºC ~ 40ºC
10% ~ 90% RH non-condensing
-40 to 70ºC
5% ~ 90% RH non-condensing
160mmX102mmX30mm (6.3"X4.0"X1.2")
0.89Kg
All For Better NetworkAll For Better Network
All For Better NetworkAll For Better Network
Shenzhen Tenda Technology Co., Ltd.
Contact us
Address:Tenda Industrial Park, No. 34-1, Shilong Rd.,Shiyan Town,
Bao’an District, Shenzhen, P.R. China 518108
Tel: 0086.755.2765.7180 Fax: 0086.755.2765.7178
E-mail: sales@tenda.com.cn Http: www.tenda.cn
Copyright statement
Obligation-free statement
Dynamic IP, Static IP, PPPoE, PPPoA, IPoA, Bridge
WEP,WPA/WPA2 and WPA-PSK/WPA2-PSK
2 detachable external omni-directional antennas (3dBi)
1 Power Port,1 RJ11 Port,4 10/100Mbps RJ45 Ports
PACKAGE CONTENTS
W300D 300Mbps Wireless ADSL2+ Modem Router
Power Adapter
Quick Installation Guide
CD-ROM (User Guide included)
Network Cable
Telephone Line*2
Voice Splitter
MINIMUM REQUIREMENTS
Internet Explorer 5.5 or Firefox 1.0 Higher
Network Adapter
CD-ROM Drive
Max.Wireless SpeedMax.Wireless Speed
InterfaceInterface
ButtonsButtons
FrequencyFrequency
Power RatingPower Rating
Operating TemperatureOperating Temperature
Operating HumidityOperating Humidity
Storage TemperatureStorage Temperature
Storage HumidityStorage Humidity
Dimension (WXDXH)Dimension (WXDXH)
Gross WeightGross Weight
Connection typeConnection type
Encryption modeEncryption mode
AntennaAntenna
CertificateCertificate
CE,RoHS
Wireless
N
Tenda is the registered trademark of Shenzhen Tenda
Technology Co. LTD in CHINA and certain other countries.
Copyright © 2007 Shenzhen Tenda Technology Co. LTD
All rights reserved. Other brands and product name
are trademarks or registered trademarks of their
respective holders.
The maximum per formance f or wireless is derived from IEEE Standard 802.11 specifications. Actual
performance can vary, including lower wireless net work capacity, data throughput rate, range and
cove rage. Performance depends on many factors, conditions and variables, i ncluding distance from
the access point, volume of network traffic, building materials and co nstruction, operating system
used, mix of wireless products used, interference and other adverse conditions.
Check the product package and contents for specific features supported. Specifications are subject to
change without notice.
Model No.: W300D
IEEE802.11b/g/n, IEEE 802.3, IEEE 802.3u, Classical IP and ARP
over ATM, PPPoA, PPPoE,ITU G.992.1/2/3/5, ANSI T1.413 Issue 2
Standards Standards
Computer
Ethernet Switch
Reset/WPS
11N Wireless
USB Adapter
11N Wireless
PCI Adapter
11N Wireless
Notebook Adapter
W322PV2.0W322PV2.0
W322UW322U

Tenda W300D Specifications

General

VPN support	PPPTP, L2TP, Ipsec
Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u, IEEE 802.3x
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi band	No
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Channels quantity	13 channels
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	300 Mbit/s
Bandwidth	2.4 GHz
Interface	LAN, WAN, WLAN
Power requirements	9V DC
USB ports quantity	0
Networking features	Ethernet, Fast Ethernet
Maximum data transfer rate	0.1 Gbit/s
Supported data transfer rates	10/100Mbit/s
WLAN data transfer rates supported	11, 54, 300 Mbit/s
Supported network protocols	IPoE, PPPoE, PPPoA, IPoA, DHCP server
Security algorithms	WEP, WPA, WPA-PSK, WPA2, WPA2-PSK, WPS
Antennas quantity	2
Antenna gain level (max)	5 dBi
Web-based management	-
RJ-11 ports quantity	1
Ethernet LAN (RJ-45) ports	4
Certification	FCC, CE, RoHS
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	9 W
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Cables included	LAN (RJ-45)
Product color	White
LED indicators	LAN, Link, Power, WAN, WLAN

Weight and Dimensions

Depth	171.95 mm
Width	118.97 mm
Height	31 mm
Weight	- g
