Tenda W311R+ User Manual

11N Wireless Broadband Router
4
1.2 Package Contents
Please unpack the box and check the following items:
¾ One W311R/W311R+ Wireless Broadband
Router
¾ One Quick Installation Guide
¾ One Power Adapter
¾ One CD-ROM
¾ One External Antenna(only for W311R+)
If any of listed items are missing or damaged, please
contact the Tenda reseller from whom you purchased
for replacement immediately.
1.3 LED Indicator and Port Description
Front Panel and LED Indicator Show
LED indicator description on front panel :( from L to R)
¾ POWER
When turns green, Always ON indicates the power
connects well.

Tenda W311R+ Specifications

General

VPN support	PPPoE/PPTP/L2TP
Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Wi-Fi standards	802.11g, Wi-Fi 4 (802.11n)
Channels quantity	11 channels
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	150 Mbit/s
Bandwidth	2.4 GHz
Rack mounting	No
Power requirements	9V DC, 1A
Minimum system requirements	Internet Explorer 5.5, Firefox 1.0+
Ethernet LAN (RJ-45) ports	3
DHCP client	-
Transmit power	0 dBmW
Antennas quantity	1
Antenna gain level (max)	3 dBi
Security algorithms	WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Certification	FCC, CE, RoHS
AC input voltage	110 - 240 V
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Product color	White
LED indicators	LAN, Power, WAN, WLAN

Weight and Dimensions

Depth	102.2 mm
Width	159.6 mm
Height	31 mm
Weight	- g
