3 - Packing Lists
Standard Accessories
4 - Specications
Item Quantity Description
Thermal Imager 1
Lens 1 Field of view = 17°× 17°, f = 9mm
Li-ion battery 1 3.7V, 2600mAH
Adaptor 1
Input AC Volts:100V to 240V, 50/60HZ, 0.3A
Output DC Volts: 5V 2400mA
Micro SD 1 8GByte
USB Cable 1
USB OTG cable 1
Non-slip Strap 1
User Manual 1
Warranty Card 1
PC Software & Installation CD 1
Gift Box & Carrying Case 1
Imaging and optical data
Field of View (FOV) / Minimum Focus
Distance
17°×17°/ 0.5m
Spatial Resolution (IFOV) 3.78mrad
Thermal Sensitivity / NETD < 0.1°C @ +30°C (+86oF) /100 mK
Image Frequency 50Hz
Focus Mode Manual
Zoom 1-32 × continuous, digital zoom
Focal Length 9mm
Focal Plane Array(FPA) / Spectral Range Uncooled microbolometer / 8-14 µm
IR Resolution 80 x 80 pixels
Image presentation
Display 2.8 in. LCD 240 x 320 pixels
Image Modes IR image, Visual Image, Image Fusion
Colour Palettes IRON Rainbow Grey, Grey Inverted
Measurement
Object Temperature Range
-20”C to +150°C (4°F to +302°F)
0°C to +350°C (+32°F to +662°F)
