FAIL
Err
Displays “FAiL” message in case of sensor failure, measurement out of range or hardware fails to
measure input signal.
Use shielded and twisted signal cables and connect shield to ground on device side. Use correct compensation cables
for T/C sensors. Connect T/C cable directly to the device connectors. Keep all signal cables away from contactors,
devices/cables emitting electrical noise, power cables.
Keep device away from contactors, devices/cables emitting electrical noise, power cables. Take precautions agains
environmental conditions like humidity, vibration, pollution and high/low temperature during installation.
Use fuse (slow 250mA 250VAC) on mains/supply input of the device. Use appropriate cables for mains connections.
Apply safety regulations during installation.
Hardware failure.
Error Message:
!
Warning:
2
Dimension
:
:
:
:
:
:
::
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
:
Display
Sensor Type
Measuring Scale
Resolution
Accuracy
Control Form
Out Output
Alarm Output
Heat SET
Alarm SET
Heat Hysteresis
Alarm Hysteresis
Proportional Band
Integral Time
Derivative Time
Control Period
Offset
Heating/Cooling
Cold. Junc. Comp.
Line Comp.
Operation Temp
Supply Voltage
Power Consump.
Weight
Altitude
Failure
DT-96:96x96, DT-72:72x72, DT-48:48x48, DT-D, DT-Y:48x96mm
4 Digits 7 Segment (PV), 4 digits 7 Segment (SV)
J,K,T,S,R type T/C, Pt100 selectable
o
-100 .. 600 C, J type T/C, (Inpt=J),
o
-100 .. 1300 C, K type T/C, (Inpt=k)
o
-100 .. 400 C, T type T/C, (Inpt=t),
o
0 .. 1750 C, S type T/C, (Inpt=S)
o
0 .. 1750 C, R type T/C, (Inpt=r),
o
-100 .. 600 C, Pt100, (Inpt=Pt)
o
-99.9 .. 600.0 C, Pt100, (Inpt=Pt.0)
o o
± 1 C or ± 0.1 C
± % 0.3 (Over full scale)
ON-OFF or P,PI,PD,PID - selectable
Relay (NO + NC), 250VAC, 2A, Resistive load, (optional SSR)
Relay (NO + NC), 250VAC, 2A, Resistive load, (only NO for Dt48)
o
Lower Limit .. Upper Limit C (H.Set)
o
AL.tY = Abs,-Abs; Lo.L .. UP.L C (A.Set)
AL.tY = rel, -rel, bnd, -bnd, bn.i, -bn.i; -100 .. +100 / -10.0 .. +10.0 (Pt.0)
o
0 .. 50 / 0.0 .. 5.0 C (H.Hys); PID is active if set to 0
o
1 .. 50 / 0.1 .. 5.0 C (A.Hys)
o
1 .. 130 C (Pb.C)
0 .. 30,0 min. (OFF if set to 0)
0.. 10,0 min. (OFF if set to 0)
4 .. 200 sec (Ct)
o
-100..+100 C / -10.0 .. +10.0 (oFFS)
Selectable (only ON-OFF control form is active for cooling)
0
o
... 50 C (T/C)
10 Ohm maks. (3 wire Pt100)
o o
-20 C... 50 C
100…240VAC, 50/60Hz
< 6VA
< 0.5 kg
< 2000 m
ALARM output is always OFF, OUT output is active according to P.Err and Ct parameters
in case of sensor failure, measurement out of range or hardware fails to measure input
signal (OUT output is OFF if Perr is 0)
:
:
Technical Specification
