Tense DT-96 User Manual

TENSE Elektronik
2
TECHNICAL SPECIFICATION
 Dimensions : DT-96:96x96, DT-72:72x72, DT-48:48x48mm
 Display : 4 Digits 7 Segment (PV), 4 digits 7 Segment (SV)
 Sensor Type : J,K,T,S,R type T/C, Pt100 selectable
 Measuring Scale : -100 .. 600
o
C, J type T/C, (Inpt=J)
-100 .. 1300
o
C, K type T/C, (Inpt=k)
-100 .. 400
o
C, T type T/C, (Inpt=t)
0 .. 1750
o
C, S type T/C, (Inpt=S)
0 .. 1750
o
C, R type T/C, (Inpt=r)
-100 .. 600
o
C, Pt100, (Inpt=Pt)
-99.9 .. 600.0
o
C, Pt100, (Inpt=Pt.0)
 Resolution : ± 1
o
C or ± 0.1
o
C
 Accuracy : ± % 0.3 (Over full scale)
 Control Form : ON-OFF or P,PI,PD,PID - selectable
 OUT Output : Relay (NO + NC), 250VAC, 2A, Resistive load, (optional SSR)
 Alarm Output : Relay (NO + NC), 250VAC, 2A, Resistive load, (only NO for DT48)
 Heat SET : Lower Limit .. Upper Limit
o
C (H.Set)
 Alarm SET : AL.tY = Abs,-Abs; Lo.L .. UP.L
o
C (A.Set)
AL.tY = rel, -rel, bnd, -bnd, bn.i, -bn.i; -100 .. +100 / -10.0 .. +10.0 (Pt.0)
 Heat Hysteresis : 0 .. 50 / 0.0 .. 5.0
o
C (H.Hys); PID is active if set to 0
 Alarm Hysteresis : 1 .. 50 / 0.1 .. 5.0
o
C (A.Hys)
 Proportional Band : 1 .. 130
o
C (Pb.C)
 Integral Time : 0 .. 30,0 min. (OFF if set to 0)
 Derivative Time : 0.. 10,0 min. (OFF if set to 0)
 Control Period : 4 .. 200 sec. (Ct)
 Offset : -100..+100
o
C / -10.0 .. +10.0 (oFFS)
 Heating/Cooling : selectable (only ON-OFF control form is active for cooling)
 Cold. Junc. Comp. : 0 .. 50
o
C (T/C)
 Line Comp. : 10 Ohm max. (3 wire Pt100)
 Operation Temp. : 0 .. 50
o
C
 Supply Voltage : 230VAC +10%, -20%, 50 - 60Hz
 Power Consumption : < 8VA
 Altitude : < 2000 m
 Failure : ALARM output is always OFF, OUT output is active according to P.Err and
Ct parameters in case of sensor failure, measurement out of range or
hardware fails to measure input signal (OUT output is OFF if Perr is 0)
Error Message:
 FAIL : Displays “FAiL” message in case of sensor failure, measurement out
of range or hardware fails to measure input signal.
 Err : Hardware failure.
Warning:
 Use shielded and twisted signal cables and connect shield to ground on device side. Use
correct compensation cables for T/C sensors. Connect T/C cable directly to the device
connectors. Keep all signal cables away from contactors, devices/cables emitting electrical
noise, power cables.
 Keep device away from contactors, devices/cables emitting electrical noise, power cables.
Take precautions agains environmental conditions like humidity, vibration, pollution and
high/low temperature during installation.
 Use fuse (F250mA 250VAC) on mains/supply input of the device. Use appropriate cables
for mains connections. Apply safety regulations during installation.

