Tense ERD-48M - Page 2

Connection
Dimensions:
“SS Out” return should directly connected to “GND pin”.
Use free-wheeling diode to protect “SS Out”
Notes:
N
L1
L2
L3
2A
Load
ERD-72M
3
2
1
4
5
10
9
8
11
12
13
14
100 .. 240 VAC
50/60Hz 6VA
no
Out
nc
+12V
50mA
START
RESET
GATE
SS Out
GND
+
2
48mm
48mm
15mm
75mm
9mm
30Vdc
(Max)
SSR
