General Information - 3360 Off-Highway Truck
BODY
Longitudinal 'V' type floor with integral transverse box-section
stiffeners. The body is exhaust heated and rests on resilient
impact absorption pads.
Body wear surfaces are high hardness (360-440 BHN)
abrasion resistant steel. Yield strength of plates 1 000 MPa
(145 000 lbf/in²).
Plate Thicknesses:
Floor ........................................................... 19 mm (0.75 in)
Side ............................................................ 10 mm (0.39 in)
Front, lower ................................................ 10 mm (0.39 in)
ROPS Cabguard SAE J1040 Feb 86. ISO 3471
Volumes:
Struck (SAE) ................................................ 26 m³ (34 yd³)
Heaped 3:1 ................................................... 32 m³ (42 yd³)
Heaped 2:1 (SAE) ........................................ 35 m³ (46 yd³)
SERVICE CAPACITIES
Engine Crankcase and Filters .............. 55 litres (14.5 US gal)
Transmission and Filters...................... 85 litres (22.5 US gal)
Cooling System ................................. 157 litres (41.5 US gal)
Fuel Tank ........................................... 606 litres (160 US gal)
Steering Hydraulic Tank ...................... 61 litres (16.1 US gal)
Steering System ..................................... 72 litres (19 US gal)
Body and Brake Cooling Tank .............. 216 litres (57 US gal)
Body and Brake Cooling System .......... 258 litres (68 US gal)
Planetaries (Total)................................ 43 litres (11.4 US gal)
Differential............................................ 52 litres (13.7 US gal)
Front Ride Strut (Each) .......................... 14 litres (3.7 US gal)
Rear Ride Strut (Each) .......................... 17 litres (4.5 US gal)
Power Takeoff ......................................... 4 litres (1.1 US gal)
* * * *
VEHICLE WEIGHTS (MASS)
TABLE965
kg lb
Chassis, with hoists
Body, standard
Net Weight
30 500
10 500
41 000
67 250
23 150
90 400
PAYLOAD, maximum
54 430 120 000
Maximum Gross Weight* 95 430 210 400
FOR UNIT EQUIPPED WITH OPTIONAL HARD ROCK
BODY:
Chassis, with hoists
Body, with wear plates
Net Weight
30 500
13 000
43 500
67 250
28 650
95 900
PAYLOAD, maximum
51 930 114 500
Maximum Gross Weight* 95 430 210 400
* Maximum permissible gross vehicle weight with options,
attachments, full fuel tank and payload.
WEIGHT DISTRIBUTION
Front Axle Rear Axle
Empty %
Loaded %
47
34
53
66
