RMX SERIES
1-11
RMX Series Terex South Dakota 483018 - 3/15
OPERATION GUIDELINES
7. Jib Extension
(Optional)
Push to extend jib boom “OUT”.
Always have one pin installed to prevent jib
movement.
Pull to retract jib boom “IN”.
8. Hydraulic Tools
(Optional)
Push to select tool circuit number 1.
Turn tool “OFF” before operating other functions.
Pull to select tool circuit number 2, if equipped.
9. Two-Speed
Throttle
*Auxiliary Let
Down Power
(Optional)
With engine running, the throttle is activated.
Push and release to increase engine RPM.
Push and release to return to engine idle.
With engine “OFF”, the auxiliary let down power is activated.
Push and hold to turn on auxiliary let down power.
Release to shut off auxiliary let down power.
NOTE: *Can be included with two-speed throttle circuit. When vehicle engine is disabled,
the auxiliary let down power can be activated by the two-speed throttle switch.
NOTE: *Do not operate longer than 30 seconds. Continuous operation will drain battery
and/or overheat pump motor.
10. Engine Stop/Start
(Optional)
Push and hold to start engine. Release when engine starts.
Push and release to stop engine.
Can also be used to stop the Aerial Device in an
emergency.
IN
OUT
457444
JIB
EXTEND
THROTTLE
PUSH/RELEASE
TWO SPEED
431560B
DC POWER
PUSH/HOLD
457452
ENGINE
PUSH/RELEASE
STOP/START
437033
