Section 000-0000
3
SM 1618 Rev 1 11-00
General Information - TR100 Mining Truck
BODY
Longitudinal 'V' type floor with integral transverse box-
section stiffeners. The body is exhaust heated and rests on
resilient impact absorption pads.
Body wear surfaces are high hardness (360-440 BHN)
abrasion resistant steel. Yield strength of plates 1 000 MPa
(145 000 lbf/in²).
Plate Thicknesses:
Floor ......................................................... 19 mm (0.75 in)
Side .......................................................... 10 mm (0.39 in)
Front, lower............................................... 10 mm (0.39 in)
ROPS Cabguard SAE J1040 Feb 86. ISO 3471
Volumes:
Struck (SAE) ......................................... 41.6 m³ (54.4 yd³)
Heaped 2:1 (SAE) ................................ 57.0 m³ (74.5 yd³)
TYPICAL NOISE LEVELS
OPERATOR EAR (ISO 6394) ....................................83 dbA
*EXTERIOR SOUND RATING
(SAE J88 JUN 86)...................................................... 93 dbA
*The above result is for the mode giving the highest exterior
sound level when measured and operated as per the
prescribed procedures of the standard. Results shown are
for the unit in base configuration.
Note: Noise Level Exposure to the operator and bystander
personnel may be higher depending upon proximity to
buildings, rock piles, machinery etc.. The actual job site
Noise Level Exposure must be measured and applicable
regulations complied with in respect to Employee Hearing
Protection.
SERVICE CAPACITIES
Engine Crankcase and Filters.......... 134 litres (35.4 US gal)
Transmission and Filters..................... 100 litres (26 US gal)
Cooling System ................................ 304 litres (80.3 US gal)
Fuel Tank ....................................... 1 090 litres (288 US gal)
Steering Hydraulic Tank .................... 61 litres (16.1 US gal)
Steering System.................................... 72 litres (19 US gal)
Body and Brake Cooling Tank ......... 297 litres (78.5 US gal)
Body and Brake Cooling System ...... 564 litres (149 US gal)
Planetaries (Total) ............................. 57 litres (15.1 US gal)
Differential .......................................... 61 litres (16.1 US gal)
Front Ride Strut (Each) ........................ 27 litres (7.1 US gal)
Rear Ride Strut (Each)......................... 18 litres (4.8 US gal)
Power Takeoff ........................................ 4 litres (1.1 US gal)
Air Conditioning Compressor ...... 0.135 litres (0.036 US gal)
* * * *
VEHICLE WEIGHTS (MASS)
kg lb
Chassis, with hoists 53 240 117 380
Body, standard 15 380 33 900
Net Weight 68 620 151 280
PAYLOAD, maximum 90 720 200 000
Maximum Gross Weight* 159 340 351 280
FOR UNIT EQUIPPED WITH OPTIONAL BODY LINER
PLATES:
Chassis, with hoists 53 240 117 380
Body, with wear plates 20 910 46 100
Net Weight 74 150 163 480
PAYLOAD, maximum 85 190 187 800
Maximum Gross Weight* 159 340 351 280
* Maximum permissible gross vehicle weight with options,
attachments, full fuel tank and payload.
WEIGHT DISTRIBUTION Front Axle Rear Axle
Empty % 49 51
Loaded % 34 66
