5-65-6
Never Leave SeatNever Leave Seat
Watch Inside DualsWatch Inside Duals
Keep Wheels LevelKeep Wheels Level
can be pushed over the edge later.can be pushed over the edge later.
Before raising the body, make sure the rear wheels are on firm level ground. IfBefore raising the body, make sure the rear wheels are on firm level ground. If
one wheel is higher than the other, a twisting strain is imposed upon the bodyone wheel is higher than the other, a twisting strain is imposed upon the body
hinge pins, hoists and chassis. Stop the machine, allow the engine to slow tohinge pins, hoists and chassis. Stop the machine, allow the engine to slow to
idle, shift the transmission to 'NEUTRAL' and apply the brakes with theidle, shift the transmission to 'NEUTRAL' and apply the brakes with the
Parking-Emergency Brake control to hold the machine stationary.Parking-Emergency Brake control to hold the machine stationary.
Push the body control lever back into the 'RAISE' position and accelerate thePush the body control lever back into the 'RAISE' position and accelerate the
engine. Decelerate the engine to slow the raising speed as the hoists approachengine. Decelerate the engine to slow the raising speed as the hoists approach
their maximum extension. When the body has been raised to the desiredtheir maximum extension. When the body has been raised to the desired
height, release the control lever into the 'HOLD' position until the body is to beheight, release the control lever into the 'HOLD' position until the body is to be
lowered. Do not hold the lever in the 'RAISE' position when the hoists are fullylowered. Do not hold the lever in the 'RAISE' position when the hoists are fully
extended to prevent unnecessary hydraulic system relief valve operation.extended to prevent unnecessary hydraulic system relief valve operation.
NEVER 'JUMP DUMP' the machine by bouncing the rear tyres against a stopNEVER 'JUMP DUMP' the machine by bouncing the rear tyres against a stop
block, or otherwise jarring the body in its raised position to dislodge stuck orblock, or otherwise jarring the body in its raised position to dislodge stuck or
frozen material. The tremendous loads that this practice develops on the bodyfrozen material. The tremendous loads that this practice develops on the body
pin area, chassis and hydraulic system can cause needless, extensivepin area, chassis and hydraulic system can cause needless, extensive
stresses.stresses.
Once the load has been dumped, push the control lever down into the 'FLOAT'Once the load has been dumped, push the control lever down into the 'FLOAT'
position to allow the body's weight to lower it to the chassis. If the body doesposition to allow the body's weight to lower it to the chassis. If the body does
not begin to lower by its weight, push the control lever down into the 'LOWER'not begin to lower by its weight, push the control lever down into the 'LOWER'
position and power the body down until it begins to lower by gravity. Thenposition and power the body down until it begins to lower by gravity. Then
release the control lever into the 'FLOAT' position.release the control lever into the 'FLOAT' position.
